Organic Zirconium Crosslinker SL-EXP6605

SL-EXP6605 is suitable for water-based gel fracturing fluid system. It can be used to crosslink guar gum and its derivatives and polymers.

inquire now

Product Description

SL-EXP6605 has delayed cross-linking and heat and shear resistance. The formed gel can withstand temperatures of 360℉(182℃). It has a wide pH range and can be cross-linked under both acidic and alkaline conditions. It can also be used for high-mineralization brine. It has strong adaptability, good stability, low dosage, and high cross-linking efficiency.

Technical & Engineering Information

SL-EXP6605 is an organic zirconium crosslinking agent. Zirconium compounds (Zr4+) have strong affinity for hydroxyl and carboxyl groups and can form stable chemical bonds with the functional groups (-OH, -COOH) to form high-viscosity gel. Various polyol ligands achieve the purpose of delayed crosslinking by shielding and delaying the release of zirconium ions; and after the introduction of organic ligands, the stability is improved. Due to the formation of multi-nuclear complex ions, the strength of the unit crosslinking point is increased, thereby improving the temperature and shear resistance of the gel.

Technical Indicators

Item

Indicator

Appearance

Transparent Liquid

Color

Light yellow to yellow

Odor

Slightly mild smell

PH

7-9

Density, 20℃

1.1-1.3 g/cm3

Flash point

≥80℃

Solubility in Water

Soluble


Recommended Treatment

SL-EXP6605 can be used for cross-linking of HPG, CMHPG and polymers; after swelling, add PH regulator, then directly and evenly add this product, stir thoroughly.

Applicable pH range: 2-6; 9-11

Temperature resistance: 160-180℃

0.45% CMHPG + 0.2% Gel performance: 180℃, 170s-1 ,2 hours, viscosity>80mPa·s

Packing and Storage

SL-EXP6605 is supplied in 200kg high density polyethylene (HDPE) drums or 1000kg IBC. Keep it away from extreme conditions such as places near flames or direct sunlight.

Shelf life is 2 years.
